特   性:

Q           本车适应装载1只 LD1、LD3、LD4、LD8集装箱或2只LD2集装箱；

Q           整车车架选用优质矩形管和槽钢焊接而成，中间设计有花纹走道；

Q           过桥式设计，可使车与车之间串联载货；

Q           前后轮采用GB10823标准的超耐磨实芯轮胎，使用寿命长，型号为400-8；

Q           翻动式的限位机构，转盘的左右两侧都有手柄控制，限位可靠；

Q           滚筒设计有2排，共33只。

Q           拖车转架能进行360度旋转，每旋转90度能自动停止，方便集装箱装卸。并设置有踏板，在需要时避开自停装置。

Q           刹车由拖把控制，拖把抬起或放下都可刹车；

Q           拖车尾部安装有E型后拖钩，具有弹簧自锁功能；

Q           整车经喷砂除锈后，外表面采用热镀锌处理；

技术参数：

长 Length	4370mm	自重 Weight	870kg
宽 Width	1860mm	载重量 Loading capacity	3000kg
高 Height	560mm	时速 Max speed	25km/h
平台工作高度 Working surface height	515mm	最小转弯半径 Min truning radius	≤5000mm

Speciiality:

Q           Designed to carry and handle one container(LD1、LD3、LD4、LD8) or two containers (LD2) in airport;

Q           Frame is welded with high quality rectangular steel pipes and channel steel.checker steel plate walkway is in its middle;

Q           Two-part designed,convenient for container transferring between trailers connected in series;

Q           Front and rear wheels are high quality,extremely wear-resisting and solid heavy-duty tires,model:400-8(GB10823),long life for use;

Q           Each side of turntable has handles to control turning stoppers.both sfe and reliable;

Q           Equipped with two rows of rollers(in 33 rollers);

Q           Turntable can trun 360 degree and stop automatically with every 90 degree turning,convenient for loading .Foot padel designed to avoid automatic stop when needed;

Q           Parking brake is actuated by lowering or lifting towbar;

Q           E-shaped rear hitch with a spring self-locking device;

Q           Surface of frame is hot dip galvanized after abrasion blasting treatment;
